Stainless steel tubes are applied when a higher corrosion resistance is required. They are often used in the process industry, the food and pharma industry, carbon capture and for water treatment, for example. Van Leeuwen supplies stainless steel tubes both from EU and from non-EU origin.
| Product | Seamless stainless round tubes, cold-finished |
|---|---|
| Standard |
ASTM/ASME A/SA213- ASTM A269, EN 10216-5 TC1/TC2 |
| Dimensions |
6.35 x 0.89 mm to 139.7 x 4 mm other dimensions on request |
| Lengths |
5 to 7 m other lengths and fixed lengths on request |
| Delivery conditions |
Cold finished, bright annealed, annealed and pickled or polished grit 240 |
| Materials |
Material number 1.4301/1.4307 1.4401/1.4404 1.4541 1.4571 Steel grade (ASTM/ASME/AISI) TP 304/304L TP316/TP316L TP 321 TP 316Ti other materials on request |
| Certification | 3.1 or 3.2 acc. to EN 10204 |
| Origin | EU and non-EU |
| Product | Seamless stainless round tubes, hot-finished |
|---|---|
| Standard |
ASTM A312/ASME SA269 ASTM/ASME A/SA 312 EN10216-5 TC1/TC2 |
| Dimensions |
33.4 x 6.35 mm to 323.9 x 9.52 mm other dimensions on request |
| Lengths |
5 to 7 m other lengths and fixed lengths on request |
| Delivery conditions |
Hot-finished, annealed and pickled |
| Materials |
Material number 1.4301/1.4307 1.4401/1.4404 1.4541 1.4571 Steel grade (ASTM/ASME/AISI) TP 304/304L TP316/TP316L TP 321 TP316Ti |
| Certification | 3.1 or 3.2 acc. to EN 10204 |
| Origin | EU and non-EU |
| Product | Welded stainless process tubes, not annealed |
|---|---|
| Standard | EN 10217-7 TC1/TC2 |
| Dimensions |
12 x 1.5 mm to 813 x 4 mm other dimensions on request |
| Lengths |
6 m other lengths and fixed lengths on request |
| Delivery conditions |
Not annealed, brushed or pickled |
| Materials |
Material number 1.4301 / 1.4307 1.4401 / 1.4404 1.4541 1.4571 other materials on request |
| Certification | 3.1 acc. to EN 10204 |
| Origin | EU |
| Product | Welded stainless process tubes, annealed |
|---|---|
| Standard |
EN 10217-7 TC1/TC2 ASTM/ASME A/SA 312 |
| Dimensions |
6 x 1 mm to 610 x 9.5 mm (1/4" S5S to 24" S40S) other dimensions on request |
| Lengths |
6m other lengths and fixed lengths on request |
| Delivery conditions |
Bright annealed / annealed and brushed / annealed and pickled |
| Materials |
Material number 1.4301 / 1.4307 1.4401 / 1.4404 1.4541 1.4571 other materials on request |
| Certification | 3.1 acc. to EN 10204, TC 1/2 |
| Origin | EU and non-EU |
| Product | Welded stainless tubes, annealed and pickled |
|---|---|
| Standard | ASTM A-312 / A-999 |
| Dimensions | 2" up to and incl. 10" sched10s |
| Lengths | 11.8 m |
| Delivery conditions |
Annealed and pickled |
| Materials | 304L and 316L |
| Certification | EN 10204/3.1 |
| Origin | Non EU |
| Product | Welded stainless round decoration and construction tubes |
|---|---|
| Standard | EN 10296-2 |
| Dimensions |
20 x 1.5 mm to 114.3 x 3 mm other dimensions on request |
| Lengths | 6 m |
| Delivery conditions |
Brushed or polished grit 320 |
| Materials |
Material number 1.4301 / 1.4307 |
| Origin | EU |
| Product | Welded stainless round dairy tubes |
|---|---|
| Standard | EN 10357/TC1 |
| Dimensions |
18 x 1 mm to 129 x 2 mm (annealed) 154 x 2 mm to 204 x 2 mm (not annealed) |
| Lengths | 6 meter fix |
| Delivery conditions |
Pickled or polished grit 320 |
| Materials |
1.4301 / 1.4307 1.4401 / 1.4404 |
| Certification | 3.1 acc. to EN 10204 |
| Origin | EU |
| Dimensions |
Diameter: 15 mm up to 108 mm Wall thickness: 1 up to 2 mm |
|---|---|
| Lengths | 6 meter |
| Delivery conditions |
not annealed |
| Materials | 1.4401 |
| Certification | 3.1 according to EN 10204 |
| Origin | EU |
